GLSand
The GLSand was first released in 2009 and has evolved into a household name in the hospitality industry. With units now operating in more than 100 countries. We are proud to have some of the most amazing locations and properties using our equipment to reduce their glass waste footprint.
Specifications
W581mm (23") x H1346mm (53") x D482mm (19")
Weight: 90kg (200lbs) 100kg packed (220lbs)
Reduction: 10:1 (Safe to handle sand)
Noise: 60-90db
Motor Size: 1.5kw
Feed Capacity: Single Feed 300kg/ph
Bin Size: 20l (5 Gallon) 40kg (85lbs) Full
Bin Capacity: 160 standard beer or 60 standard wine
Power: 220v 50/60hz
Consumables: Download Specs
Warranty: 12 months excluding consumables
Specifications
W686mm (27") x H1067mm (42") x D610mm (24")
Weight: 120kg (264lbs) 130kg packed (287lbs)
Reduction: 10:1 (Safe to handle sand)
Noise: 60-90db
Motor Size: USA 2.2kw CSA
Feed Capacity: Single Feed Wide Mouth 300kg/ph
Bin Size: 20l (5 Gallon) 40kg (85lbs) Full
Bin Capacity: 160 standard beer or 60 standard wine
Power: 220v 50/60hz (NEMA L6-20 Plug)
Consumables: Download Specs
Warranty: 12 months excluding consumables
GLS2.0
The GLS2.0 offers further refinement to the GLSand. Offering a lower profile design for bench top and marketing housing integration, a slightly wider mouth for the odd shaped bottles, bin full sensors, dual filter system, kevlar flaps and a clear tub. This is our newest and most user friendly single feed unit.
AFSMini
The AFSMini is our Commercial Auto Feed System crusher suited for small community waste projects or larger establishments like stadiums, breweries, casinos, ski resorts etc. The unit is available with an manual lever or electric bin lift and is capable of handling 2T/ph bottle throughput. Switch the core for cullet or sand output.
Specifications
W1571mm (62") x H2277mm (90") x L4246mm (167")
Weight: 2t (2.2USt) 5t Screen out.
Reduction: 10:1 Max
Noise: Industrial
Bi-Product: Sand or Cullet (1 hr conversion)
Feed Capacity: Auto Feed 2t/ph
Bin Size: 1cbm (2t Max or approx 4000 beer bottles)
Motor Size: 3.0kw
Power: 440v 50/60hz
Operators: 1-2
Warranty: 12 months excluding consumables
Specifications
W2609mm (103") x H3555mm (140") x L6661mm (262")
Weight: 7t (7.7USt) 15t Screen out
Reduction: 10:1 Max
Noise: Industrial
Bi-Product: Sand or Cullet (1hr conversion)
Feed Capacity: Auto Feed 5t/ph
Bin Size: 1cbm (2t Max or approx 4000 beer bottles)
Motor Size: 22kw
Power: 440v 50/60hz
Operators: 1-2
Warranty: 12 months excluding consumables
AFSMaxi
The AFSMaxi is our Industrial Auto Feed System crusher suited for larger community/municipal waste projects with multiple configurations. The unit is loader fed and is capable of handling 5T/ph bottle throughput. Switch the core for cullet or sand output or remove the bottom screen for 15T/ph increased throughput and coarser output.
MFx
The MFx is our first multi-feed by hand crusher suited for larger commercial opeartors like casinos, cruise ships and smaller community run recycling programs. The unit is hand fed (4 bottles at a time) by up to two operators standing on the platform. Capable of handling 1T/ph bottle throughput to sand, cullet or aggregate.
Prototype Spec
W1370mm (54") x H2050mm (81") x L2510mm (99")
Weight: 1000kg
Reduction: 10:1 Max
Noise: Industrial
Bi-Product: Sand or Cullet (1hr conversion)
Feed Capacity: Auto Feed 1t/ph
Bin Size: Variable Bag (Max or approx 4000 beer bottles)
Motor Size: 3.0kw
Power: 440v 50/60hz
Operators: 1-2
Warranty: 12 months excluding consumables
Prototype Spec
W1700mm (67") x H1500mm (59") x L2000mm (79")
Weight: 1500kg
Reduction: 10:1 Max
Noise: Low
Bi-Product: Cullet (1hr conversion)
Feed Capacity: Auto Feed
Bin Size: Custom
Motor Size: 3.0kw
Power: 440v 50/60hz
Operators: 1-2
Warranty: 12 months excluding consumables
FGx
The FGx is our first design specifically catered to processing flat float glass to recyclable cullet. The unit is hand fed to a short conveyor loading the glass into the fully contained crushing mechanism. This unit is fully shrouded allowing dust free operation directly adjacent to window glass cutting tables.
LV/AFScreen
Our screening equipment is available in GLS and AFS configurations matching your screening to your crusher output delivering 5 grades of screened glass bi-product.
Size | GLS | AFSMini | AFSMaxi |
|---|---|---|---|
<0.4mm | 15% | 15% | 39% |
0.4 - 1.1mm | 30% | 30% | 35% |
1.1 - 1.7mm | 20% | 22% | 14% |
1.7 - 3.4mm | 25% | 25% | 9% |
>3.4mm | 10% | 8% | 3% |
Specifications
W1100mm (43") x H1555mm (61") x L1100mm (43")
Weight: 230kg (606lbs)
Decks: 5 (Custom on request)
Noise: Industrial
Motor Size:
Feed Capacity: Bucket Feed 500kg/ph (LV) or 2t/ph (AFS)
Bi-Product: Graded Sand
Power: 220v 50/60hz
Consumables: Download Specs
Warranty: 12 months excluding consumables
